RRC8517 - Stiffener Assembly Body Part Land Rover Range Rover Defender

RRC8517 - Door Check Bracket – Rear

Sold out

€7,70 - €7,70

€7,70

€7,70 - €7,70

€7,70

Tip: Log in to your account to unlock volume discounts on this item.

Genuine: Original manufacturer part. This product is the original part designed and produced by the vehicle manufacturer.

Door Check Bracket - Rear is a mounting bracket within the rear door check mechanism.

It anchors the door checker (door stay) to the body, providing the fixed point against which the torsion-bar check arm acts to hold the rear door at its open detents and to limit door travel.

Vehicle Model Land Rover Defender up to 2016

Fitment Notes Superseded by LR016768
DEFENDER 1987-2006 — Rear end door check mechanism with torsion bar; bracket for rear door checker
DEFENDER 2007-2016 — Rear end door check mechanism with torsion bar; 90 & 110 wheelbase, Hard Top, Station Wagon 3 & 5 Door, from VIN 7A000001

Alternative Codes

10006281RRC8517

Not available

This item is currently unavailable. Contact us for alternatives.

Notify me when back in stock

Rather wait until it is in stock? Leave your email address and we will email you the moment it arrives. No newsletter.

Job kits containing this part

This part is included in 0 job kit(s) below. Pick the kit that matches your vehicle and job, then add what you need.

Frequently asked questions

What is the Rear Door Check Bracket (RRC8517)?

The Rear Door Check Bracket (RRC8517) anchors the rear door checker, or door stay, to the body on the Land Rover Defender. It gives the fixed point the torsion-bar check arm acts against, holding the rear door at its open detents and limiting how far the door can swing.

Has the RRC8517 door check bracket been replaced by a newer part?

Yes, RRC8517 has been superseded by part number LR016768, the current Land Rover replacement for the rear door check bracket. It fits the same rear door check mechanism. If you're working from an older parts list, order the current supersession to be sure of availability.

Which Defenders does this rear door check bracket fit?

This bracket fits the rear door check mechanism on the Defender from 1987 to 2016, including 90 and 110 Hard Top and Station Wagon 3 and 5 door models, with later builds from VIN 7A000001. It's for the torsion-bar type checker, so confirm your rear door uses that mechanism.

Can the rear door check bracket be fitted at home?

Fitting the rear door check bracket is usually a straightforward DIY job with basic hand tools. It bolts to the body at the rear door and the door checker attaches to it. Access can be tight, so it typically helps to have the door supported while you work.
