NRC9700GALV - Spring Seat – Front – Galvanised

- €19,30

€19,30

€19,30 - €19,30

€19,30

Aftermarket: Quality alternative. This is a quality alternative, designed to fit and function like the original part, often at a more competitive price.

Spring Seat for the front coil spring suspension. It forms the lower seat that locates and supports the base of the front coil spring on the axle, providing the mounting platform at the lower shock absorber position.

Galvanised for corrosion resistance in the exposed underbody environment.

Vehicle Model Land Rover Defender up to 2016
Land Rover Discovery 1 1989-1998 (L318)
Range Rover Classic up to 1994

Fitment Notes DEFENDER 1987-2006 — Front shock absorber spring seat (lower); also rear suspension on 90" wheelbase 1983-2006
DEFENDER 2007-2016 — Front shock absorber spring seat, from (V) 7A000001
DISCOVERY 1 1989-1998 — Front and rear shock absorber spring seat, from (V) FA393361 to (V) WA799999
RANGE ROVER CLASSIC 1986-1994 — Front and rear shock absorber spring seat; 1986-1991 to (V) HA610293, 1992-1994 from (V) JA610294

Alternative Codes

NRC9700GALVNRC9700

In stock 6 units

4 · Gouda 2 · Drachten

Express delivery available

8 more on the way · ETA 22-07-2026

When will my order arrive?

Order before 15:00 (Mon–Fri): same-day dispatch for in-stock items.
UPS Express (order before 14:00): dispatched today, delivered tomorrow where available.
Netherlands / Belgium / Germany: 2–4 working days.
Other EU countries + UK: 4–8 working days.
Outside EU/UK: delivery times vary — contact us for an estimate.

8 more units on the way — expected 22-07-2026. Orders beyond current stock are reserved from incoming stock and shipped as soon as they arrive.

Items may ship from multiple warehouses at no extra cost.

Job kits containing this part

This part is included in 0 job kit(s) below. Pick the kit that matches your vehicle and job, then add what you need.

Frequently asked questions

What is the NRC9700GALV spring seat and where does it sit on the suspension?

The NRC9700GALV is a galvanised front spring seat that locates the base of the front coil spring on the axle, providing the lower mounting point for the spring and shock absorber. It fits Defender 1987 to 2016 (from VIN 7A000001 for 2007-on), Discovery 1 (VIN FA393361 to WA799999), and Range Rover Classic 1986 to 1994.

What's the difference between NRC9700GALV and the standard NRC9700?

NRC9700GALV is the galvanised version of the spring seat. The galvanising provides significantly better corrosion resistance than the plain steel NRC9700, making it the preferred choice for vehicles used in wet climates or off-road conditions where mud and water accelerate rusting.

How do front spring seats fail and when should they be replaced?

Spring seats corrode and pit over time, particularly at the spring contact point. A corroded seat can cause the spring to sit unevenly, increasing stress on the coil end and accelerating spring failure. Replace if pitting or distortion is found during suspension work, or when fitting new coil springs.
