EAC2414L - Large injector O-ring V8 EFI Engine Part Land Rover Range Rover Defender, Discovery, Range Rover

EAC2414L - Injector O-Ring – Large – V8 EFI

- €6,30

€6,30

€6,30 - €6,30

€6,30

Tip: Log in to your account to unlock volume discounts on this item.

OEM: Made by an Original Equipment Manufacturer. This part is made by an original equipment manufacturer or under their license, ensuring compatibility and quality.

Injector O-Ring (Large) - the larger of the two sealing O-rings fitted to each fuel injector, sealing the injector into the fuel rail.

Fitted to the V8 EFI petrol engine. It seals the pressurised fuel connection at the upper end of the injector, preventing leakage where the injector meets the fuel rail.

Vehicle Model Land Rover Defender up to 2016
Land Rover Discovery 1 1989-1998 (L318)
Range Rover Classic up to 1994
Range Rover Classic 1994-2001 (P38)

Fitment Notes DEFENDER 1987-2006 — 4.0L V8 L/R EFI Petrol, injector O-ring (large)
DISCOVERY 1 1989-1998 — V8 EFI Petrol, from VIN FA393361
RANGE ROVER CLASSIC 1986-1994 — 3.5L/V8 EFI, Less Catalyst
RANGE ROVER P38 1994-2001 — 4.0L/4.6L V8 EFI Petrol

Alternative Codes

EAC2414LEAC2414LX

In stock 12 units

12 · Gouda 0 · Drachten

Express delivery available

When will my order arrive?

Order before 15:00 (Mon–Fri): same-day dispatch for in-stock items.
UPS Express (order before 14:00): dispatched today, delivered tomorrow where available.
Netherlands / Belgium / Germany: 2–4 working days.
Other EU countries + UK: 4–8 working days.
Outside EU/UK: delivery times vary — contact us for an estimate.

Items may ship from multiple warehouses at no extra cost.

Job kits containing this part

This part is included in 0 job kit(s) below. Pick the kit that matches your vehicle and job, then add what you need.

Frequently asked questions

What is the Large Injector O-Ring for the V8 EFI used for?

The large injector O-ring is the upper of the two sealing rings on each fuel injector, sealing the injector into the fuel rail on the V8 EFI petrol engine. It seals the pressurised fuel connection where the injector meets the rail. Fitted to Defender, Discovery 1, Range Rover Classic and Range Rover P38.

What size is this injector O-ring?

The large injector O-ring measures 31mm outside diameter, 22mm inside diameter and 8mm thick. It's the larger of the two O-rings on each V8 EFI injector. Match these dimensions against your old seal, as the smaller lower O-ring is a different size and isn't interchangeable.

How many O-rings do I need for the V8 EFI injectors?

The V8 EFI engine has eight injectors, each using this large O-ring, so a full set needs eight. They're sold individually, so order the quantity the job needs. The smaller lower O-ring on each injector is a separate part.

Should these O-rings be reused?

No, injector O-rings should not be reused once disturbed. On the V8 EFI engine the rubber takes a set and hardens with fuel and heat exposure, so a reused O-ring often weeps fuel at the rail. Fit new O-rings whenever the injectors come out, and check for leaks after refitting.
